Premium Wholesale 304 Stainless Steel Male Thread | RFQ Sourcing Details

Stainless Steel Butt Welded Union BW-BW Stainless Steel Union is a type of fitting used in plumbing and piping systems to connect two pipes together in a manner that allows for easy disassembly and reassembly.

It is designed to join pipes or tubes of similar or different sizes while providing a convenient means for maintenance, repair, or modifications in the system. Usedful Connection: Female(Inside) Thread, Male (Outside) Thread, Male to Female Thread, Butt Welding, Socket Welded.

For the Angle: Straight Union and 90 Degree Elbow Union.

Dimension(mm) Size DN ΦD L L1 SW 1/8" /4" /8" /2" /4" " /4" /2" " /2" " " Thread Casting Connector Stainless Steel 304 316 Welding Female Pipe Union Size 1/8'' ~ 4'' Material we can do 304 304L 316 316L CF8 CF8M CF3 CF3M 303 WCB S25C S45C 17-4 CN7M 8620 SCM440 SCM21 Material in stock ASTM A351 CF8(304), ASTM A351M CF8M(316) Thread BS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B 0203/2(PT), KS B0221/2(PT), etc..

Working Pressure 150LB Temperature -20°C to +220°C Physical Property Tensile strength≥485. Mpa, Yield strength≥205. Mpa, Elongation≥35% Surface Pickling and Peeling Model Union Connection Welding and Female Shape Equal Certificate ISO 9001:2015, ISO14001:2015, CE, ROHS, KC, etc..

Application Suitable for Air, Natural Gas, Oil, Steam, Water and so on.

Package Cartons without pallet Cartons with pallet Cartons with wooden boxes Or as buyer's requirements Port Ningbo/Shanghai, China Delivery Details According to the quantities and specifications of each order A complete stock to provide fast deliveries for small orders.

Normal delivery times is from 30 to 45 days after receiving the deposit Sample Offer free samples and freight collected. OEM and ODM Accepted and professional. Buyer's drawing or designs are available Material test report is available upon request when placing order. QUESTION? ANSWER 1. Are you a factory?

Yes, Welflow is a factory located in Wenzhou, Zhejiang, China. 2. Do you have any requirements of MOQ? No limited to MOQ but the difference in unit price. 3. Payment Terms Typically 30% T/T as deposit, 7
